The detail

Magnetostat Se is a reference valve line stage whose amplification and coupling strategy is centred on custom magnetic devices. NAT combines a zero-feedback triode circuit with transformer-based signal transfer to reduce the number of conventional passive elements encountered by the music signal.

Its high-energy power supply, extensive regulation and separated functional sections are designed to maintain dynamic stability while keeping noise low. Balanced and single-ended interfaces allow the preamplifier to work with a broad range of sources and power amplifiers.

The chassis uses thick machined aluminium, premium connectors and hand-assembled internal wiring. Component selection focuses on close-tolerance parts and long-life valves suitable for sustained reference-system use.

Complete product information

Manufacturer technical data

Complete technical specification

Complete manufacturer specifications and engineering information for Magnetostat Se.

Configuration
Absolute Zero Feedback Triode
Frequency Response
4 Hz to 300 kHz, -3 dB; 20Hz to 20kHz, +/-0.02dB @ (RCA connection)
Input Impedance
>20 kohms
Output Impedance
<90 ohms @ (RCA connection)
Power Requirements
100 VAC to 250 VAC (set in factory only) @ 50 to 60 Hz, max. 50 VA
THD & N
<0.08 % @1V output
Gain
14 dB (X 5) @ RCA or XLR output
Dimensions
19" (483 mm) wide , 16.9" (430 mm) deep , 7.2" (185 mm) high (max. dimensions)
Weight
approx. 73 lb. (33 kg)/unit + 6.6 lb. (3 kg)/power supply
TOTAL Weight
approx. 106 lb. (48 kg) packed
Operation
Single-ended (RCA) or balanced (XLR)
Noise
<112 dB "A" weighted
Stereo Separation
>100dB @ 10 kHz
Tube Complement
4 x 6S46G-V per unit (N.O.S. & military grade)
