The detail

The ideal partner

Available without drives or with 4TB or 8TB capacity Zero configuration required Automatically serves all added music Fibre Network provides complete isolation from network noise 4-port network switch simplifies cabling and makes fibre easy UPnP (Openhome) compatible USB 3.0 Micro type B for connection to computer SMB support for transferring over the network Gigabit Ethernet Thick-panelled CNC Aluminium construction

Audiophile-grade network switch

4 ports

With 4 network ports LUMIN L2 can simplify your wiring and remove the need for cheap (and electrically noisy) switches around your hi-fi.

Fibre networking

2x SFP ports allow optical fibre networking input and output, completely electrically isolating your hi-fi from the rest of your network.

Low-noise design

Shielded, low-noise power supply, thick and rigid CNC aluminium chassis, and spacious layout all help provide untouched data to your network player.

Complete product information

Manufacturer technical data

Complete technical specification

Complete manufacturer specifications and engineering information for Lumin L2 MUSIC LIBRARY & NETWORK SWITCH.

Storage
Diskless, 4TB (2 × 2TB) or 8TB (2 × 4TB) 2.5-inch SSD configurations
Power supply
Internal 100–240V auto-ranging low-noise supply in a shielded compartment
Physical
Finish: Black anodised aluminium Raw anodised aluminium
Dimensions and weight
350 × 350 × 60.5mm; 6kg
Dimensions
350mm (W), 350mm (D), 60.5mm (H), 6kg
Audio formats
DSF, DIFF and DoP; FLAC, ALAC, WAV and AIFF; MP3
Connections
USB 3.0 Micro-B; 2 × Gigabit RJ45; 2 × Gigabit SFP; 2 × reserved USB 3.0 Type-A
Protocol
UPnP AV with OpenHome; SMB network transfer; JPLAY Certified

Internal Storage:

No drives, 4TB (2x 2TB) or 8TB (2x 4TB) 2.5" SSD

Supported Audio File Formats:

DSD Lossless:

DSF (DSD), DIFF (DSD), DoP (DSD)

PCM Lossless:

FLAC, Apple Lossless (ALAC), WAV, AIFF

Compressed (lossy) Audio:

Connections:

USB 3.0 Micro Type B Slave for connection to computer 2x Gigabit Ethernet Network (1000BASE-T) RJ45 2x Industry-standard SFP 2x USB 3.0 Type A reserved for future use

Power Supply:

Internal 100–240V AC auto-ranging Low-noise Shielded power supply compartment for reduced interference with delicate electronics

Lumin L2 MUSIC LIBRARY & NETWORK SWITCH
