Lumin T3X Network Player | Swedish Statement Audio

Collection/Lumin/Lumin T3X Network Player

The detail

Main features

Features our latest processing system Dual ES9028Pro SABRE DAC featuring dual-mono operation New integrated toroidal linear power supply Fibre Network provides complete isolation from network digital noise Dual-Network interface with built-in Network Switch Dual USB ports for additional flexibility and digital audio output Upsampling and downsampling to every supported format up to DSD256/PCM384 Leedh Processing Volume control Roon Ready, Spotify Connect, MQA, TIDAL, TIDAL Connect, Qobuz, TuneIn and AirPlay-compatible

New upgraded components Internal ultra-low-noise linear power supply First LUMIN T-series player with a built in linear power supply Ultra-low-noise and high dynamic range Extra large toroidal transformer

Dual Network with Optical Fibre Network support Fibre SFP provides complete isolation from network noise Use simultaneously with RJ45 as a network switch (e.g. connect one to router and one to LUMIN L1/L2 or NAS)

Complete product information

Manufacturer technical data

Complete technical specification

Complete manufacturer specifications and engineering information for Lumin T3X Network Player.

Power supply: Internal toroidal linear supply with low-noise regulation and shielding
Digital output: USB: native DSD512 and PCM to 384kHz; BNC S/PDIF: PCM to 192kHz and DSD64 DoP
Outputs: XLR balanced 6Vrms; RCA unbalanced 3Vrms
Playback: DSD512 (22.6MHz, 1-bit); PCM up to 384kHz, 16–32-bit stereo
Physical: Finish: Black anodised aluminium Raw anodised aluminium
Dimensions and weight: 350 × 350 × 60.5mm; 6kg
Dimensions: 350mm (W), 350mm (D), 60.5mm (H), 6kg
DAC: Dual ESS SABRE32 ES9028PRO in dual-mono operation; fully balanced analogue stage
Network: Gigabit RJ45 and SFP optical network with built-in switch
Streaming: UPnP/OpenHome, Roon Ready, Qobuz Connect, TIDAL Connect, Spotify Connect, AirPlay-compatible, gapless playback and on-device playlists
File formats: DSF, DIFF and DoP; FLAC, ALAC, WAV and AIFF; MP3 and MQA
Control: Lumin app for iOS, Android, Apple silicon Mac and Chromebook; firmware upgradeable

DSD Support:

Up to DSD512 22.6MHz, 1-bit

PCM Support:

Analog Output Stage:

Dual ESS SABRE32 ES9028Pro DAC chips Fully balanced layout with high-quality components Completely redesigned analogue buffer includes audiograde output capacitor and ultra-low-noise and high dynamic range Discreet clock system for precision timing Precision 32-bit internal digital volume

Upsampling rates & bit depths:

DSD256 upsampling option for all files PCM 384kHz upsampling option for all files

Digital Output Stage:

Native DSD512 support PCM 44.1–384kHz, 16–32-bit, Stereo

BNC SPDIF:

PCM 44.1kHz–192kHz, 16–24-bit DSD (DoP, DSD over PCM) 2.8MHz, 1-bit

Power Supply:

Internal 100–240V AC auto-ranging Low-noise Shielded power supply compartment for reduced interference with delicate electronics

Product details

Product photography & engineering

Product details.

Lumin product photography, construction, materials and finish.

Lumin T3X Network Player — Lumin T3X Network Player · manufacturer photograph — 01
Lumin T3X Network Player · manufacturer photograph
Showing the model’s form, proportions, materials and finish.

Photography: Lumin and the Swedish Statement Audio catalogue.
