The detail

The O/Reference is DeVore Fidelity's flagship four-piece loudspeaker system. Two O/Ref/A main speakers use bronze horn-loaded high-frequency drivers and a bronze-chassis 10-inch paper woofer, while two active O/Ref/B Bassmachines extend the system into the lowest octave. Finish and final configuration are completed in consultation with the DeVore workshop.

Complete product information

Manufacturer technical data

Complete technical specification

Complete manufacturer specifications and engineering information for DeVore Fidelity ORANGUTAN O/Reference.

Configuration
Four-piece system: two O/Ref/A main speakers and two O/Ref/B Bassmachines
Tweeters
1-inch silk dome in a cast and machined bronze horn; 0.75-inch silk-dome super-tweeter in a bronze horn
Bassmachine
11-inch reinforced-aluminium woofer with 2.25-inch excursion and matched passive radiator
Bass amplification
Dedicated 700W Class-D amplifier per Bassmachine with analogue crossover, phase, subsonic filter and 20Hz/35Hz EQ
Main woofer
10-inch paper cone, cast-bronze chassis, AlNiCo magnet, titanium former and bronze phase plug
Sensitivity
98dB/W/m
Impedance
12 ohms
Bandwidth
15Hz–50kHz
Dimensions
18 × 35.5 × 12 inches each, including stands
DeVore Fidelity ORANGUTAN O/Reference

Product details

Product photography & engineering

Product details.

DeVore Fidelity product photography, construction, materials and finish.

Photography: DeVore Fidelity and the Swedish Statement Audio catalogue.
