The detail

The Bt Type 2.0 brings Premium-series engineering to a more accessible platform. A tungsten-loaded counterweight places the centre of gravity closer to the pivot, accommodates heavier cartridges without an auxiliary weight and improves tracing stability.

The four-layer counterweight damper combines aluminium, polymer, paper and rubber-bonded tungsten. A stainless-steel arm pipe and pivot path, dense polyester/carbon internal damping, four large radial bearings, copper wiring and a 5-pin DIN output are used to minimise resonance and preserve a clear transient response.

Complete product information

Manufacturer technical data

Complete technical specification

Complete manufacturer specifications and engineering information for Glanz Tech MH-10Bt 2.0.

Output
5-pin DIN with copper cable
Internal wiring
Copper
Compatible cartridge weight
14-40 g
Tonearm weight
0.78 kg
Counterweight damping
Four materials: aluminium, polymer, paper and rubber-bonded tungsten
Balance
Static balance
Total length
277 mm
Effective length
254 mm
Pivot-to-spindle distance
239 mm
Offset angle
22 degrees
Overhang
15 mm
Mounting shaft
16 mm diameter
Mounting hole
24 mm
Mounting-board depth
Up to 29 mm; optional base for 40 mm
Tracking-force scale
0.1 g; over 6 g range, 3 g per revolution
Main structure
Chrome-plated brass with SUS304 vertical axis and arm pipe
Arm-pipe damping
Polyester fibre and dense carbon fibre
Bearings
4 radial bearings
Headshell
12 g plug-in SUS304 headshell with damping material
Glanz Tech MH-10Bt 2.0

Product details

Product photography & engineering

Product details.

Glanz Tech product photography, construction, materials and finish.

Photography: Glanz Tech and the Swedish Statement Audio catalogue.
